Basic information

Our automatic feeding machine has many features that specifically solve the problems of feeding poultry birds on small and medium chicken farms. This automatic feeding machine allows automatic feeding. It has automatic moving systems without manual push.  Automatic chicken feeding machine can be set to time and quantify the amount of feed for the chickens. It has a total automatic feeding system. It does not require any person to operate it during the feed conveying and feeding process

The automatic feeding machine is a poultry machine that takes feed from a central hopper or bin out in order to feed the birds continuously all day. Instead of filling the score of separate feeding troughs, the poultry farmer fills just one which is the hopper and does it this process once a day. Also, a manpower hopper is the beginning of the main feed line

Nowadays, many farmers will choose to use the automatic feeding machine which helps them to complete their work of raising chickens in order to save labor and improve their working efficiency that is why the automatic feeding machine is selected by many poultry farmers today

Automatic feeding machine has helped to realize the automatic feeding of the chickens, and no need for the poultry farmers to feed them by themselves

Product description

The automatic feeding machine distributing systems consist of with an endless chain driven by the motor gears. It has a feed pan sensor where the ends of each feeding line controls the motors on and have to achieve automatic feeds delivery. When all the feeds pan are filled up with feed, the control box will stop the motors from working. After all the feeds have been eaten up, the automatic feeding machine restarts it feeding processes again

After the feeds are put into the hopper and the machine is started, the operations are continuous. Feeds in the hopper are moved to an outlet ports at the bottom of hopper. It falls through the opening onto the slowly moving chain. The chain, which travels through the trough, carries the feeds along with it out to the birds. The chicken feeding system run smoothly and the feeds traveling from the hopper flows evenly into the trough so that every chicken get the fresh feeds

The birds feed through the trough. The chicken breed feeds from a tank outside the chicken house where transports are from the feed system into the feeds silos, and then the conveying device transports feed to the traveling hopper according to the time which is set. When the last traveling hoppers are filled with feeds, then the conveying devices are stopped automatically

Customers part of the poultry growing business benefit from our customised solutions, visiting our page of products to learn more

1. Egg laying chicken rearing system

2. Click rearing system

3. Broiler rearing system

4. Other poultry system

The one stop shop and solution of turnkey poultry farm project, contact us to give you full solution from the designing of poultry house, layout and quotation of poultry equipment and cages, delivery and installation...

Components

1. The automatic cage system has a feeding tank which is used to store the feeds

2. It has feeding silos

3. It has traveling hopper

4. It has a feed discharge

Specification list of chicken cages matching automatic feeding machine

The sizes of most customers choosing of chicken cage system/equipment and floor raising chicken system/equipment are

1.Egg laying chicken cage

128 birds/set, 4 tiers/set, 32 cells/set, 4 birds/cell, LXWXH/set: 2mX2.5mX2.12m, LXWXH/cell: 1960mmX350mmX380mm

2.Broiler chicken cage

120 birds/set, 3 tiers/set, 6 cells/set, 20 birds/cell, LXWXH/set: 1.1mX1.9mX2.56m, LXWXH/cell: 1050mmX1000mmX635mm

3.Pullet chicken cage

96 birds/set, 4 tiers/set, 8 cells/set, 12 birds/cell, LXWXH/set: 1.25mX1.5mX2.9m, LXWXH/cell: 1200mmX600mmX625mm

4.Breeder chicken cage

280 female and 40 male/set, 4 tiers/set, 8 cells/set,  35 female and 5 male/cell, LXWXH/set: 3.66mX2.6mX3.7m, LXWXH/cell: 3600mmX1250mmX800mm

5.Broiler floor raising system/equipment

80 birds/m2, LXWXH/chicken house: 100mX10mX4m

6.Pullet floor raising system/equipment

100 birds/m2, LXWXH/chicken house: 100mX10mX4m

Features

1. The automatic feeding machine can be set to time and quantify the amount of feed for the birds

2. It will be possible to adjust or control the amount of feeds delivered by machine to the birds

3.  It encourages natural feeding behavior. The automatic closing design keeps food safe from pests

4. The automatic feeding machine holds large amount of feeds which makes feeding of the birds easier

5. The automatic feeding machine spill-edge reduces messes and waste

6. The galvanized plates ensure stability while molded plastic parts provide resistance to weather and ultra violet rays

Advantages

1. The automatic feeding machine can be used on a farm of 60,000 chickens

2. The automatic feeding machine is 85% more energy efficient than the chain feeder

3. An automatic chicken feeding machine can replace the work of more than ten people. This reduces labor and improves the farming level and breeding efficiency

4. The automatic feeding machine can be turned on automatically

5. The height of the powder auger can be adjusted and can be freely retracted on both sides until the base material is placed in the trough

6. It is convenient for the farmers to set the amount of feed and add appropriate amount with the feeding settings

7. It helps to reduce wastage of feed

8. It saves labor cost, In place of spending hours each day filling troughs, the poultry man may dump a few bags of feed into the hopper, and check the chain and feeding system

9.  Automatic feeding machine pushes the material directly and it is safe and convenient

10. Automatic chicken feeding machine can realize 10,000 chickens for 40 minutes to complete one feeding

11. Automatic chicken feeding machine is suitable for the operation of storing eggs, laying eggs, and self-control management

Our services

1. We provide detailed information to our customers

2. We sell long lasting equipments to meet our customers’ demands

3. We give our first time customers suggestions on how they should go about their poultry farm

4. We give satisfactory answers to any questions they may have concerning our products

5. We are well experienced on the product we are manufacturing

6. We follow up our customers from time to time concerning the equipments they purchased

Frequently ask questions

Q: Is automatic feeding machine effective for poultry farm?

A: Yes, the automatic feeding machine is effective for poultry farm because it saves labor cost and it improves work efficiency

Q: Does the automatic feeding machine require much labor?

A: No, it does not require much labor

Q: How does the automatic feeding machine operate?

A: When the last traveling hoppers are filled with feeds, then the conveying devices are stopped automatically
